红外收发器 HSDL-3021-021 SOT

热销商品

产品描述
数据速率Data Rate4.0Mbit/s
电源电压Supply Voltage2.4V~3.6V
25°C时的待机电流(典型值)Idle Current, Typ @ 25° C
链路范围,低功耗Link Range, Low Power0.22W
Description & ApplicationsFeatures • IrDA® Data Compliant Low Power 4.0 Mbit/s with Remote Control Infrared General • Operating temperature from -25°C ~ 85°C –Critical parameters are guaranteed over temperature and supply voltage •  VCC supply 2.4 to 3.6 volts •  Miniature package –  Height: 2.5 mm –  Width: 8.0 mm –  Depth: 3.0 mm •  Integrated remote control LED driver •  Input/output interface voltage of 1.5 V •  Integrated EMI shield •  LED stuck-high protection •  Designed to accommodate light loss with cosmetic windows •  IEC 825-Class 1 eye safe •  Interface to various super I/O and controller devices •  Lead free package IrDA® Features •  Fully compliant to IrDA 1.4 Physical Layer Low Power Specifications from 9.6 kbit/s to 4.0 Mb/s –  Link distance up to 50 cm typically •  Complete shutdown for TxD_IrDA, RxD_IrDA and PIN diode •  Low power consumption –  Low shutdown current Remote Control Features •  Wide angle and high radiant intensity •  Spectrally suited to remote control function at 890 nm typically •  Typical link distance up to 8 meters (on-axis) Applications •  Mobile data communication and universal remote control –  Mobile phones –  PDAs –  Webpads
描述与应用特点 •红外线数据标准低功率4.0 Mbit / s的遥控器红外一般 •工作温度-25°C〜85°C - 关键参数都保证在 温度和电源电压 •VCC供应2.4到3.6伏 •微型封装 - 高度:2.5毫米 - 宽度:8.0毫米 - 深度:3.0毫米 •集成的远程控制LED驱动器 •输入/输出接口电压1.5 V •集成的EMI屏蔽 •LED卡住高保护 •设计,以适应与化妆品窗户的光损失 •IEC825-1级眼睛安全 •各种超级I / O和控制设备的接口 •无铅封装 IrDA®的  特点 •完全兼容1.4的IrDA物理层低功率规格从9.6 kbit / s到4.0 Mb / s的 - 传输距离通常可达50厘米 •完全关闭,RxD_IrDA TxD_IrDA和PIN二极管 •低功耗 - 低关断电流远程控制功能 •广角和高辐射强度 •光谱适合于远程控制功能,通常在890 nm •典型的链路距离可达8米(轴) 应用 •移动数据通信和万能遥控器 控制 - 手机 - 掌上电脑 - Webpads
规格书PDF
