小功率电感 NLC322522T-101K 100UH 3225-101K 101
| 电感值Inductance | 100UH |
| 误差Tolerance | ±10% |
| 额定电流Current Rating | 100mA |
| 饱和电流Current - Saturation | |
| 不同频率时的Q值Q @ Frequency | 15 @ 0.796MHz |
| 自振谐频率SRFFrequency - Self Resonant | 10MHz |
| DC电阻DCRDC Resistance (DCR) | 3.7Ω/Ohm |
| 屏蔽Shielding | 无屏蔽 Unshielded |
| Description & Applications | NLC Series NLC3225 Type FEATURES • The NLC series feature low DC resistance and high current handling capacities, making them ideal for power supply line applications. • They are available in form factors ranging from 2520 to 5650. |
| 描述与应用 | NLC系列NLC3225类型 特点 NLC系列具有低直流电阻和高电流处理能力，使它们成为理想的电源线应用。 他们的形式因素，从2520到5650不等。 |
| 规格书PDF |
