AP431RLA 电压基准电源IC 2.495V~36V SOT-23 marking/标记 A93M/A93J 可编程输出电压

热销商品

产品描述
参考类型Reference Type
输出电压VoVoltage - Output2.495V~36V
误差Tolerance±1%
温度系数Temperature Coefficient30ppm/°C
输入电压Voltage - Input2.495V~36V
阴极电流Current - Cathode300uA
输出电流IOUTCurrent - Output200mA/0.2A
Description & ApplicationsFEATURES • Precision reference voltage AP431 : 2.495V ± 1% AP431A : 2.495V ± 0.5% • Sink current capability: 200mA • Minimum cathode current for regulation: 300μA • Equivalent full-range temp coefficient: 30 ppm/oC • Fast turn-on response • Low dynamic output impedance: 0.2Ω • Programmable output voltage to 36v • Low output noise. • Packages: TO92, SOT89, SOT23, SOT25 and SOP
描述与应用特点 •精密参考电压    AP431:2.495V±1%    AP431A:2.495V±0.5% •灌电流能力时:200mA •最小阴极电流调节:300μA •等效满量程温度系数:30 PPM/℃ •快速导通响应 •低动态输出阻抗:0.2Ω •可编程输出电压为36V •低输出噪声。 •封装:TO92,SOT89,SOT23,SOT25和SOP
规格书PDF
相关型号列表
